P007 - PASSENGER/CRUISE VESSEL

View1 View2

(SISTERSHIPS - Maria Savina 1975, Lyubovj Orlova 1978, Olga Androvskaya 1977, Olga Sadovskaya 1977)

Type: passenger vessel, double-screw, three-deck motor ship with surplus freeboard, double-deck superstructure, intermwdiate engine room, bulbous bow and transon stern
Built: 1978, Kraievitsa, Yugoslavia
Classification: (contains ice class) - KM*L1 (1) A2: KM* indicates that ship was built in accordance with Rules and under supervision of Russian Register of Shipping, L1 = navigation without assistance in summer in the Arctic in the broken ice and all the year round in the freezing non-arctic seas in the light ice conditions, all the year round navigation astern an ice-breaker in the freezing non-arctic seas and in summer/autumn in the Arctic, A2 = a ship fitted with the machinery installation of the extent of automation sufficient for operation with unattended machinery spaces but attended main control station
L o.a./b.p.: 100,02/90 m
B moulded: 16,2 m
D moulded: 7 m
Summer load-line draft: 4,67 m
FDT/LDT: 4160/2886,9 mt
Light draft fore/aft: 2,16/4,67 m
DWT: 1273,1 t
Loading capacity per 1 cm draft: 10,91 t/cm
Pax capacity: 220 persons
GRT/NRT: 4251/1439 rt
Service speed loaded/in ballast: 13 knots
Navigation range: 5000 miles
Full/min staff (complement): 63/27 members.
Overall height above the base-line: 31,8 m
Cargo holds (grain): 900 CBM
Fuel stores: DO 66,4 t/high viscosity fuel 168,3 t
DO consumption under way/in port cargo operation/no cargo: 1,8/1,45/1,23 t/day
High viscosity fuel consumption under way/in port cargo operation/no cargo: 12,5/1,35/1,15 t/day
Cargo handling gear: electrical crane 12 m boom, 1 x 3,2 t
Main engine: Diesel 8M35 BF-62 B&W, 2 x 1940 KWT (2640 b.h.p.), recommended fuel cSt50 C
Aux. generators: 4 x 352 KWT
Propeller: FPP, 2 x 2,6 m
Ventilation: cargo&servise spaces - mechanically, accommodation spaces - air conditioners, vessel is fully equipped with air-conditioning system
Passenger services: comfortable cabins, restaurant, bar, movie hall, winter garden, library, souvenir shop, hairdresser's and barber's, music lounge, information deck, gym hall, bathroom
Capacity: restaurant 106 seats, stern bar 34 persons, bow bar (music hall) 60 seats, lounge 20 persons, dinning room 20 seats
GMDSS: is installed
Next SS: January, 2006
DD: freshly passed in January, 2004
Cabins: 50, first class cabins 2 x 2 persons (8,5 sq. m each), main deck cabins 28 x 4 persons, lower deck cabins 18 x 4 persons, passenger deck cabins 2 x 2 persons, total accommodation 192 persons; each cabin is equipped with WC and showers
Description: intimate small passenger ship with a well-balanced profile and an ice-reinforced hull. She has good open deck space, an outdoor observation deck plus an enclosed promenade deck for inclement weather. The ship is small with compact cabins (all outside) although they can accommodate four persons, yet comfortable
Last years the vessel was operating in North-West region of Pacific Ocean with calling to the ports of Russia, China, Japan, Korea. The vessel was trading as a pax vessel. The character of the cruises was mostly shop-tours. Duration of each cruise was between 1 and 2 weeks. Usual quantity of passengers on board the vessel was 120-150 persons.
Smoke detecting gear: installed over the whole vessel (cabins, public places, etc.)
Trading area: Far East
Price idea: 1,6 mln. USD
