Built: 1972 in Kherson, USSR
Framing: mixed
Number of Decks: three
Number of deck superstructures: two
Stern formation: plane
Material of hull: floating hull - reinforced concrete, tower - steel
Main dimensions:
Length overall - 139.5 m
Breadth overall - 32.4 m
Breadth inside - 24.0 m
Tower breadth along dock floor - 3.4 m
Tower breadth along top floor - 5.5 m
Depth - 17.0 m
Pontoon depth - 4.8 m
Displacement:
Light - 10370 t
Total with max submersion - 29260 t
Carrying capacity: 8500 t
Tonnage:
Gross - 23172.93 cbm / 8188.31 t
Net (registered) - 22154.39 cbm / 7828.41 t
Maximum submersion: 6,8 m
Time of submersion: 1.0 hour
Emersion: 1.5 hrs
Diesel-generators: 2 x ÄÃÐ - 300/750, 300 kW each
Boilers: 2 x ÊÂÂÀ 1,5/5, steam generation -
1.5 t/hour
Compressor: 1 x type 202 ÂÏ 10/8
Ballast pumps: 6 x ÎÂ2-42 ÌÊ, capacity 1500-2000
cbm/hour with head 8.8 m of water column
Cranes: 2, with loading capacity - 5 ò
Stabilized àt 8 mooring anchors 100 t each.
No docking, no repair, inspected in 2000
Inspection: Russian Far-East
Price: USD 2,75 MIO FOB
